Saddle hall

10m
x
12.2m
x
5.2m

Saddle hall 10m x 12.2m x 5.2m

10m
x
12.2m
x
5.2m
  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
In stock
Delivery throughout Europe

€6,690

excl. VAT
8 229 € incl. VAT

Questions about the product? We can helpDamián Halamček, MBA – Sales Manager
+421 904 687 065 Mon–Sun 7–20 h
hagro@hagro.sk

Description and specifications

  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
Width10m
Length12.2m
Height5.2m
ColourGreen, White
Tarpaulin900 g/m2
Entrance width3.2 m
Entrance height3.2 m
Wind resistance100 km/h
Distance between beams3.05 m
Side wall height3m

Structure

Galvanized steel pipes

Robust steel tubes that ensure the strength of the hall are protected against corrosion and rust thanks to careful galvanization, providing maximum load capacity and long durability.

Steel tubes are:

  • Designed for high load capacity and structural strength
  • Hot-dip galvanized and resistant to corrosion and rust
  • Resistant to impacts and scratches

Specifications:

  • 5-year warranty against rusting
  • Tube diameter: ø 70 mm x 42 mm (depending on the hall size)
  • Tube thickness: approx. 2 mm (varies by model)
Anchoring

Thanks to the supplied anchoring system, you can install the hall on any surface WITHOUT the need for a foundation slab!

  • Each column features a robust base plate (with pre-drilled holes for anchoring), which increases the stability of the hall and simplifies installation
  • The hall is anchored using galvanized rebar anchors driven into the ground at a specific angle, ensuring strength and resistance to wind
  • Anchoring into concrete is possible using drive-in anchors / chemical anchors (not included in the package)
Vertical arches

The main structure of the hall consists of vertical steel arches that are interconnected, forming a strong and durable framework.

  • Carefully shaped steel tubes with precise holes for bolting
  • Solid pipes connecting the segments together, along with steel tubes, increase the hall’s resistance to wind and falling snow
  • The structure does not include any support columns in the middle of the hall, maximizing the usable interior space
Pipe connection

Solid connecting elements ensure high overall stability and resistance to adverse weather conditions thanks to the thorough bolting of individual structural parts with self-locking nuts, which reduces maintenance costs.

Individual parts of the arches:

  • Inserted into each other
  • Bolted together using 2 bolts with self-locking nuts (i.e., twice)

Horizontal steel tubes:

  • Connected to the vertical arch using a robust bolt and a self-locking nut

Hall bracing:

  • The hall has additional strength thanks to bracing steel tubes or steel cables (depending on the structure), ensuring stability even in strong winds
Possibility to extend

You can extend the tent hall arbitrarily “indefinitely” and thus increase the storage area of the hall.

  • Halls with the same width can be extended
  • For this purpose, the halls must be placed one behind another
  • The edge of the tarp of the first hall is folded over the first arch of the connecting hall
  • Subsequently, the tarps are secured using rope/ratchets (depending on the size of the hall)

PVC tarpaulin and entrances

Thanks to its dense inner fabric, the 3-layer PVC tarpaulin is extremely tear-resistant and lasts for a very long time. It is also flame-retardant and blocks harmful UV radiation.

What makes our tarpaulins stand out:

  • Thanks to quality materials they are 100% waterproof
  • Up to 3x more durable than standard PVC tarpaulins (resistant to rain, snow, mould, wind and damage)
  • They have a bottom “skirt” for protection against moisture and wind
  • They let natural light through and block UV radiation
  • 3-layer tarpaulin: the bottom and top layers are PVC, the middle layer is a non-elastic fabric

Specification:

  • Various tarpaulin weights (thicknesses): 650 g/m² (20-year lifespan), 750 g/m² (22-year lifespan), 900 g/m² (25-year lifespan)
  • Available in white or green.

Once the frame is assembled, the main (roof) tarpaulin is pulled over the structure and fixed to the arch bases using a robust ratchet tensioning system.

Installing the main tarpaulin is very easy:

  • The roof tarpaulin is pulled over the frame (using ropes)
  • The tarpaulin is then tied with rope to the first and last arch and tensioned using the straps and ratchets.
  • The end tarpaulins (front and rear entrance) are fixed to the frame with the supplied rope / straps
  • Our tent halls have a manufacturer-stated lifespan of 20 years or more.
  • Thanks to the special 3-layer PVC tarpaulin the hall is durable and shows almost no wear over time.
  • Thanks to the shape of the hall, neither dirt nor snow stays on it
  • High-quality zips and stainless brass eyelets
  • Easy-to-wash tarpaulin with minimal maintenance
  • The hall can also be heated or thermally insulated (by a third-party company)

The package also includes 2 end tarpaulins together with 2 entrance gates

Vehicle access and quick entry are ensured by:

  • Entrances on both ends of the hall (front and rear)
  • Extra-large door dimensions for vehicles
  • Roll-up doors opened with a manual winch / rope (depending on the hall type)
  • The option to cut any number and size of entrances into the hall (including the sides)
  • The option not to fit the front and rear ends, turning the hall into a “tunnel” and gaining the full entrance width and height

Installation

  • Quick and easy installation (usually within 1 day) that absolutely anyone can manage.
  • Standard tools are all you need (hammer, spanner, ladder, knife…)
  • We recommend having 1 lifting device available (forklift, loader, etc.)
  • You receive complete assembly instructions + a technician on the phone free of charge for any questions during installation

Package contents

The whole hall (frame including tarpaulin) is packed in 1 or more boxes (depending on the size)

Package contents

  • Galvanised steel frame (including entrances)
  • Main PVC tarpaulin
  • Anchoring for unpaved ground (or concrete)
  • Complete assembly instructions in English
  • Adhesive tape, rope for fixing the tarpaulin, bolts, nuts and everything needed for assembly

Accessories

  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
Width: 10m
Length: 12.2m
Height: 5.2m
Colour: Green, White
Tarpaulin: 900 g/m2
Entrance width: 3.2 m
Entrance height: 3.2 m
Wind resistance: 100 km/h
Distance between beams: 3.05 m
Side wall height: 3m
  • Quick and easy installation (usually within 1 day) that absolutely anyone can manage.
  • Standard tools are all you need (hammer, spanner, ladder, knife…)
  • We recommend having 1 lifting device available (forklift, loader, etc.)
  • You receive complete assembly instructions + a technician on the phone free of charge for any questions during installation

The whole hall (frame including tarpaulin) is packed in 1 or more boxes (depending on the size)

Package contents

  • Galvanised steel frame (including entrances)
  • Main PVC tarpaulin
  • Anchoring for unpaved ground (or concrete)
  • Complete assembly instructions in English
  • Adhesive tape, rope for fixing the tarpaulin, bolts, nuts and everything needed for assembly

Extended product description

DESCRIPTION OF THE TENT HALL Premium tarpaulin hall with long service life

This tarpaulin hall combines a solid structure and high-quality materials, making it the ideal solution for protecting vehicles, storing materials or creating a covered workspace. It stands out for its robustness, high resistance to weather conditions and an exceptionally long lifespan of up to 25 years.

Technical specification of the structure

  1. Robust steel truss construction
    • Made of hot-dip galvanized steel, which resists corrosion and guarantees stability even in adverse conditions.
    • Steel tubes with an arc diameter of ø 48 × 1.5 mm and connecting tubes with the same dimensions ensure a firm fit and durability of the entire structure.
  2. Mechanical doors on both sides of the hall
    • Suitable for large vehicles, machinery or bulky materials.
  3. Spaciousness and comfort
    • The height of the tarpaulin hall is 5.2 m, which allows for easy movement and handling of tall objects.
    • The tent shape of the hall ensures effective drainage of snow and water, which contributes to greater durability and longer service life.

PVC tarpaulin with a weight of 900 g/m²

  • Superior material durability – The three-layer PVC tarpaulin consists of a top and bottom layer of PVC and a middle layer of non-elastic fabric. This combination provides exceptional strength, water resistance and impermeability.
  • Adapted to extreme conditions – The material does not change its dimensions with temperature changes, resists UV radiation and can handle strong winds or a layer of snow.
  • Fireproof and safe – The tarpaulin meets the Class B fire resistance standard, making it suitable for industrial and safety-critical applications.
  • Easy maintenance and repair – In the event of mechanical damage, the tarpaulin can be easily repaired by welding, thus preserving its functionality and appearance.

Practical use of the hall

  • Protection of large vehicles and equipment – Ideal for trucks, buses, tractors or construction machinery.
  • Spacious storage areas – Suitable for storing bulky materials, equipment or supplies.
  • Covered Workspace – Perfect for service and maintenance work that requires covered and stable conditions.

Agricultural use

Possibility to store crops, hay or agricultural machinery safely from adverse weather.

With this tarpaulin hall, you will not only get a durable and flexible space, but also long-term protection for your property. Thanks to its solid construction, premium materials and ease of use, it is an ideal choice for anyone who needs a functional and durable solution for various purposes.
