Saddle hall

15.25m
x
36.6m
x
7m

Saddle hall 15.25m x 36.6m x 7m

15.25m
x
36.6m
x
7m
  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
In stock
Delivery throughout Europe

€23,690

excl. VAT
29 139 € incl. VAT

Questions about the product? We can helpDamián Halamček, MBA – Sales Manager
+421 904 687 065 Mon–Sun 7–20 h
hagro@hagro.sk

Description and specifications

  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
Width15.25m
Length36.6m
Height7m
ColourGreen, White
Tarpaulin900 g/m2
Entrance width5.5 m
Entrance height4.88 m
Wind resistance100 km/h
Distance between beams3.05 m
Side wall height3.5 m

Structure

Galvanized steel pipes

Robust steel tubes that ensure the strength of the hall are protected against corrosion and rust thanks to careful galvanization, providing maximum load capacity and long durability.

Steel tubes are:

  • Designed for high load capacity and structural strength
  • Hot-dip galvanized and resistant to corrosion and rust
  • Resistant to impacts and scratches

Specifications:

  • 5-year warranty against rusting
  • Tube diameter: ø 70 mm x 42 mm (depending on the hall size)
  • Tube thickness: approx. 2 mm (varies by model)
Anchoring

Thanks to the supplied anchoring system, you can install the hall on any surface WITHOUT the need for a foundation slab!

  • Each column features a robust base plate (with pre-drilled holes for anchoring), which increases the stability of the hall and simplifies installation
  • The hall is anchored using galvanized rebar anchors driven into the ground at a specific angle, ensuring strength and resistance to wind
  • Anchoring into concrete is possible using drive-in anchors / chemical anchors (not included in the package)
Vertical arches

The main structure of the hall consists of vertical steel arches that are interconnected, forming a strong and durable framework.

  • Carefully shaped steel tubes with precise holes for bolting
  • Solid pipes connecting the segments together, along with steel tubes, increase the hall’s resistance to wind and falling snow
  • The structure does not include any support columns in the middle of the hall, maximizing the usable interior space
Pipe connection

Solid connecting elements ensure high overall stability and resistance to adverse weather conditions thanks to the thorough bolting of individual structural parts with self-locking nuts, which reduces maintenance costs.

Individual parts of the arches:

  • Inserted into each other
  • Bolted together using 2 bolts with self-locking nuts (i.e., twice)

Horizontal steel tubes:

  • Connected to the vertical arch using a robust bolt and a self-locking nut

Hall bracing:

  • The hall has additional strength thanks to bracing steel tubes or steel cables (depending on the structure), ensuring stability even in strong winds
Possibility to extend

You can extend the tent hall arbitrarily “indefinitely” and thus increase the storage area of the hall.

  • Halls with the same width can be extended
  • For this purpose, the halls must be placed one behind another
  • The edge of the tarp of the first hall is folded over the first arch of the connecting hall
  • Subsequently, the tarps are secured using rope/ratchets (depending on the size of the hall)

PVC tarpaulin and entrances

Thanks to its dense inner fabric, the 3-layer PVC tarpaulin is extremely tear-resistant and lasts for a very long time. It is also flame-retardant and blocks harmful UV radiation.

What makes our tarpaulins stand out:

  • Thanks to quality materials they are 100% waterproof
  • Up to 3x more durable than standard PVC tarpaulins (resistant to rain, snow, mould, wind and damage)
  • They have a bottom “skirt” for protection against moisture and wind
  • They let natural light through and block UV radiation
  • 3-layer tarpaulin: the bottom and top layers are PVC, the middle layer is a non-elastic fabric

Specification:

  • Various tarpaulin weights (thicknesses): 650 g/m² (20-year lifespan), 750 g/m² (22-year lifespan), 900 g/m² (25-year lifespan)
  • Available in white or green.

Once the frame is assembled, the main (roof) tarpaulin is pulled over the structure and fixed to the arch bases using a robust ratchet tensioning system.

Installing the main tarpaulin is very easy:

  • The roof tarpaulin is pulled over the frame (using ropes)
  • The tarpaulin is then tied with rope to the first and last arch and tensioned using the straps and ratchets.
  • The end tarpaulins (front and rear entrance) are fixed to the frame with the supplied rope / straps
  • Our tent halls have a manufacturer-stated lifespan of 20 years or more.
  • Thanks to the special 3-layer PVC tarpaulin the hall is durable and shows almost no wear over time.
  • Thanks to the shape of the hall, neither dirt nor snow stays on it
  • High-quality zips and stainless brass eyelets
  • Easy-to-wash tarpaulin with minimal maintenance
  • The hall can also be heated or thermally insulated (by a third-party company)

The package also includes 2 end tarpaulins together with 2 entrance gates

Vehicle access and quick entry are ensured by:

  • Entrances on both ends of the hall (front and rear)
  • Extra-large door dimensions for vehicles
  • Roll-up doors opened with a manual winch / rope (depending on the hall type)
  • The option to cut any number and size of entrances into the hall (including the sides)
  • The option not to fit the front and rear ends, turning the hall into a “tunnel” and gaining the full entrance width and height

Installation

  • Quick and easy installation (usually within 1 day) that absolutely anyone can manage.
  • Standard tools are all you need (hammer, spanner, ladder, knife…)
  • We recommend having 1 lifting device available (forklift, loader, etc.)
  • You receive complete assembly instructions + a technician on the phone free of charge for any questions during installation

Package contents

The whole hall (frame including tarpaulin) is packed in 1 or more boxes (depending on the size)

Package contents

  • Galvanised steel frame (including entrances)
  • Main PVC tarpaulin
  • Anchoring for unpaved ground (or concrete)
  • Complete assembly instructions in English
  • Adhesive tape, rope for fixing the tarpaulin, bolts, nuts and everything needed for assembly

Accessories

  • Entrances at both ends, opened with a manual winch
  • Waterproof, UV-resistant PVC tarpaulin with a 20+ year lifespan
  • Galvanised steel frame
  • Ground anchors for unpaved surfaces included
Width: 15.25m
Length: 36.6m
Height: 7m
Colour: Green, White
Tarpaulin: 900 g/m2
Entrance width: 5.5 m
Entrance height: 4.88 m
Wind resistance: 100 km/h
Distance between beams: 3.05 m
Side wall height: 3.5 m
  • Quick and easy installation (usually within 1 day) that absolutely anyone can manage.
  • Standard tools are all you need (hammer, spanner, ladder, knife…)
  • We recommend having 1 lifting device available (forklift, loader, etc.)
  • You receive complete assembly instructions + a technician on the phone free of charge for any questions during installation

The whole hall (frame including tarpaulin) is packed in 1 or more boxes (depending on the size)

Package contents

  • Galvanised steel frame (including entrances)
  • Main PVC tarpaulin
  • Anchoring for unpaved ground (or concrete)
  • Complete assembly instructions in English
  • Adhesive tape, rope for fixing the tarpaulin, bolts, nuts and everything needed for assembly

Extended product description

DESCRIPTION OF THE TENT HALL

The tent hall has a really solid and reliable construction – truss with hot-dip galvanizing . These features ensure that the hall does not rust and that its lifespan is long. Thanks to this, the investment in it is profitable.

The tent hall is strong, durable and stable thanks to the curved tubes with a diameter of ø 60 × 1.8 mm . They will not be surprised even by the harsh weather conditions.

Another important parameter is the connecting tubes with a diameter of ø 60 × 1.5 mm , which play a key role in ensuring a firm connection of the individual parts of the structure. Their role is also to ensure the stability of the hall.

Getting into the hall is really easy, because our tent hall has mechanical doors on both sides , so you can comfortably enter it or store necessary things there, such as machines, materials, and other equipment.

The height of the straight part of the walls reaches up to 3.5 meters , which provides enough space for a wide range of uses, from storage to various industrial or agricultural activities.

The entire hall is designed with durability and long-term use in mind. Its lifespan is up to 25 years , making it a cost-effective solution for long-term needs.

The meaning of the weight of a PVC tarpaulin 900 g/m²

Why should you choose a 900 g/m² PVC tarpaulin? This type of tarpaulin combines high quality, durability and an extremely long lifespan, which can reach up to 25 years.

Protection from wind and snow : Thanks to its strength, the PVC tarpaulin can withstand not only intense winds (up to 100 km/h), but also higher loads, such as snow.

Easy to repair : It is possible that the PVC tarpaulin on your tent hall will tear over time. But that is no reason to worry, as you can repair it by welding.

Extreme durability : PVC tarpaulin is made of polyester fabric covered with a layer of PVC. This three-layer composition includes a top and bottom layer of PVC, between which there is a strong, non-elastic fabric. Such a structure ensures that the tarpaulin is impermeable, waterproof and does not lose its shape even after prolonged exposure to adverse conditions.

Adapting to all conditions : Whether the hall is exposed to strong winds, rain or freezing temperatures, the PVC tarpaulin retains its properties and reliably protects your property. It even meets fire safety standards, being classified as Class B in reaction to fire.

Do you want to build a hall yourself? No problem! We include detailed instructions with each of our tent halls, thanks to which everyone can handle the assembly. Our hall is designed so that even a beginner can assemble it without special tools or skills. Just follow our simple instructions and your new hall will be worth a shot.

If you would like us to build this tent hall for you, please contact us for a price.
